SKU: CQE-CO-02031
Crystal Quest

4.8 ( 50 reviews)

$15,832.65

✔ Need a Quote? Call a Currenhaus Team Member: (805)-334-5208
✔ FREE & FAST Shipping: In Stock and Ready to Ship
✔ Authorized U.S. Dealer
✔ Lowest Price Match Guaranteed

Description

Crystal Quest High-Flow Reverse Osmosis (RO) System is a powerful commercial water purification solution engineered for industrial, agricultural, and municipal-grade applications. Built to support demanding environments, this system offers configurable flow rates ranging from 10,000 to 50,000 gallons per day (GPD) and is ideal for well water treatment, food and beverage production, agricultural irrigation, hydroponic farming, mobile treatment trailers, and large-scale potable or process water needs.

Each system arrives fully assembled, pre-plumbed, and pre-wired, minimizing installation time and cost. The compact, powder-coated aluminum skid frame ensures easy access for maintenance, efficient use of space, and long-term performance under continuous operation.

Key Use Cases

  • Mobile water treatment trailers
  • Agriculture and irrigation
  • Pool water recovery systems
  • Food & beverage processing
  • Manufacturing and cooling operations
  • Municipal or emergency water delivery

Standard Features

  • Thin-film composite (TFC) RO membranes
  • Stainless steel pressure membrane housings
  • High-efficiency centrifugal pump (1.5 HP to 6 HP depending on GPD model)
  • Dual media vessels with 0.5-micron zeolite and coconut shell activated carbon
  • Low- and high-pressure protection switches
  • Automatic feed shut-off
  • Feed and system pressure gauges
  • Flow control with integrated chemical cleaning ports
  • Permeate and concentrate flowmeters
  • Integrated TDS monitor (feed and product water)
  • C-150 microprocessor controller with LED indicators
  • Industrial-grade coated aluminum skid frame (modular and expandable)

Automation & Safety Features

  • Automatic motorized feed valve
  • Delayed high-pressure pump start-up
  • Automatic system shutdown at tank full
  • Low/high-pressure fault protection
  • Pretreatment lockout compatibility
  • Feed water flush cycle on shutdown
  • TDS alarm for out-of-spec product water

Operational Benefits

  • Rated for 10,000–50,000 GPD capacity
  • Compact footprint, ideal for both stationary and mobile installations
  • Modular frame supports expansion and upgrade flexibility
  • Easy service access with minimal downtime
  • Low operating and maintenance costs
  • Fully assembled, factory-tested, and CE compliant
  • Made in the USA; backed by a 1-year limited warranty
  • Compatible with off-grid power setups and mobile trailer systems

Mobile Integration Ready

This system is well-suited for enclosed trailer deployment for mobile water treatment. A minimum 6x10 tandem axle trailer is recommended for safe clearance, ventilation, and accessory space (pretreatment, generator, tanks).

  • Dry Weight: 400–650 lbs depending on model
  • Loaded Weight: ~600–900 lbs including membranes, plumbing, and housing water
  • Power Requirement: 110V/220V, 50/60 Hz, single-phase
  • Recommended Generator: 5,500W continuous minimum; 6,500W+ ideal to support motor surge at startup

Pretreatment Advisory

To ensure optimal membrane life and performance, appropriate pretreatment is essential. A sediment filter (0.5–5 micron), GAC carbon filter, and antiscalant dosing system may be required based on your local water conditions.
System supports water sources with:

  • Max Hardness: 15 GPG
  • Max TDS: 2000 ppm
  • pH Range: 3–11

Contact us if you’d like assistance reviewing your source water or configuring a pretreatment setup.

Available Upgrade Options

  • Stainless steel rotary vane pump for corrosive environments
  • Concentrate recycle valve to increase system recovery efficiency
  • Digital TDS controllers (single or dual-line)
  • Inline conductivity controller for remote monitoring
  • C-200 or IF controller upgrade with Ethernet & flush controls
  • Integrated chemical dosing pump outlet
  • Blending valve for custom final water quality
  • Permeate sampling port for membrane diagnostics
  • Voltage configurations: 110V or 240V (50/60 Hz)
  • Protective wood crate packaging for freight delivery

Need a Quote or Custom Setup?

Whether you’re building a mobile trailer system, installing in a plant, or upgrading an existing operation, we can help you configure the right model and accessories for your needs.

Shipping is free, and no sales tax applies to your order.
Request a quote or contact us for expert configuration support.

We accept

pngimg.com - paypal_PNG7.png__PID:8a7c843a-2227-4649-a602-786624b58d6f
Google_Pay_Logo.svg.png__PID:339110ba-8f9a-486f-bbd4-8a7c843a2227

Authorized U.S. Dealer

All Crystal Quest® systems ship directly from certified U.S.-based facilities.

Fast & Free Shipping

Most units are built-to-order and ship quickly with no added delivery fees.

Easy Returns & Exchanges

Eligible systems can be returned within 30 days. We’re here to help if anything’s not right.

Lifetime Support

Call, chat, or email anytime. Our U.S.-based team is ready to assist before and after your purchase.

High-Flow Reverse Osmosis System Specifications

GPM

10,000

15,000

20,000

30,000

40,000

50,000

Model No

CQE-CO-02031

CQE-CO-02032

CQE-CO-02033

CQE-CO-02034

CQE-CO-02035

CQE-CO-02036

Dimensions

49" x 33" x 54"

63" x 39" x 54"

63" x 39" x 54"

41" x 143" x 80"

41" x 143" x 80"

41" x 143" x 80"

Weight (lbs)

385

400

415

N/A

N/A

N/A

Membrane Size

4040 TFC HF1

4040 TFC HF1

4040 TFC HF1

4040 TFC HF1

4040 TFC HF1

4040 TFC HF1

# of Membranes

6

8

10

14

16

20

Motor HP

1.5

1.5

1.5

3

3

3

Voltage

110/220

110/220

110/220

110/220

110/220

110/220

Hertz (cycles)

50/60

50/60

50/60

50/60

50/60

50/60

Feed Connection

1"

1"

1"

2"

2"

2"

Product Connection

1"

1"

1"

1.5"

1.5"

1.5"

Waste Connection

1"

1"

1"

1"

1"

1.5"

Minimum Feed Pressure

45 psi

45 psi

45 psi

45 psi

45 psi

45 psi

Minimum NaCl - % Rejection

96%

96%

96%

96%

96%

96%

Minimum Feed (GPM)

14

21

30

30

30

30

Maximum NaCl - % Rejection

98.5%

98.5%

98.5%

98.5%

98.5%

98.5%

Maximum Feed (GPM)

30

30

50

50

50

50

Maximum Hardness (GPG)

15

15

15

15

15

15

Maximum TDS

2000 ppm

2000 ppm

2000 ppm

2000 ppm

2000 ppm

2000 ppm

Operating Pressure

150 psi

150 psi

150 psi

150 psi

150 psi

150 psi

pH Range

3-11

3-11

3-11

3-11

3-11

3-11

GPD 10,000 Specifications

Dimensions

49" x 33" x 54"

Feed Connection

1"

Weight (lbs)

385

Product Connection

1"

# of Membranes

6

Minimum Feed (GPM)

14

Motor HP

1.5

Operating Pressure

150 psi

GPD 15,000 Specifications

Dimensions

63" x 39" x 54"

Feed Connection

1"

Weight (lbs)

400

Product Connection

1"

# of Membranes

8

Minimum Feed (GPM)

45 psi

Motor HP

1.5

Operating Pressure

150 psi

Yes, the CapturePro X200 comes with both Wi-Fi and Bluetooth connectivity. This allows you to easily transfer images and videos to your smart devices and control the camera remotely using a compatible app.

GPD 20,000 Specifications

Dimensions

63" x 39" x 54"

Feed Connection

1"

Weight (lbs)

415

Product Connection

1"

# of Membranes

10

Minimum Feed (GPM)

28

Motor HP

3

Operating Pressure

150 psi

GPD 30,000 Specifications

Dimensions

41" x 143" x 80"

Feed Connection

2"

Weight (lbs)

N/A

Product Connection

1.5"

# of Membranes

14

Minimum Feed (GPM)

42

Motor HP

3

Operating Pressure

150 psi

GPD 40,000 Specifications

Dimensions

41" x 143" x 80"

Feed Connection

2"

Weight (lbs)

N/A

Product Connection

1.5"

# of Membranes

16

Minimum Feed (GPM)

56

Motor HP

5

Operating Pressure

150 psi

GPD 50,000 Specifications

Dimensions

41" x 143" x 80"

Feed Connection

2"

Weight (lbs)

N/A

Product Connection

1.5"

# of Membranes

20

Minimum Feed (GPM)

70

Motor HP

5

Operating Pressure

150 psi

High-Flow Reverse Osmosis FAQs

Get Answers to Commonly Asked Questions

Is the system equipped for automated operation?

Yes. The system includes a C-150 Microprocessor Controller that automates key functions such as delayed high-pressure pump startup, tank full shutdown, pre-treatment lockout, feed water flush at shutdown, and high TDS alarm shutdown. Ethernet functionality is available with the optional C-200 upgrade.

How is the system shipped and delivered?

Units are skid-mounted, fully assembled, and tested before shipping. They arrive ready for final utility connections.

Can the system run continuously, or does it need downtime?

The system is designed for continuous 24/7 operation, with downtime only required for scheduled maintenance.

What kind of maintenance does the system require?

Basic maintenance includes replacing prefilters, monitoring pump pressure, and performing periodic membrane cleanings.

What type of membranes are used in this system?

It uses thin-film composite (TFC) membranes housed in stainless steel vessels. These membranes are known for their high salt rejection, long lifespan, and compatibility with a wide range of feed water conditions.

How long do RO membranes typically last?

Membranes generally last 3–5 years with proper pretreatment and maintenance.

Can I monitor water quality in real time?

Yes, the system includes permeate and feed TDS displays for monitoring water quality. Optional upgrades like the SWP Digital Dual TDS or Conductivity Controllers provide enhanced accuracy and continuous monitoring of system performance.

Is the system customizable to specific site or water quality needs?

Absolutely. This unit is modular and offers multiple upgrade options such as a concentrate recycle valve, chemical pump outlet, blending valve, and voltage customization. These features allow for greater flexibility in industrial or commercial setups.

What types of applications is this RO system best suited for?

This high-flow reverse osmosis system is engineered for demanding commercial and light industrial applications requiring high daily water output. Typical use cases include manufacturing plants, agriculture and greenhouse irrigation, food and beverage production, and large-scale commercial facilities needing consistent purified water.
