5,200 lb Cantilever Lift – Hydraulic Boat Lift System, 114″ x 127″

5,200 lb Cantilever Lift – Hydraulic Boat Lift System, 114″ x 127″ – Hewitt by Boat Lift Distributors

SKU: L0HC5212RC
Boat Lift Distributors

$9,642.00

✔ Authorized U.S. Dealer
✔ Lowest Price Match Guaranteed
✔ Nationwide Shipping – Contact Us for Personalized Quote
✔ Questions? Call a Currenhaus Team Member: (805)-334-5208

Description

The 5,200 lb Cantilever Hydraulic Boat Lift is the ideal solution for boat owners seeking the strength of a cantilever design without the hassle of manual cranking. Built from high-grade aluminum and powered by durable hydraulic rams, this lift offers reliable performance with the convenience of wireless remote operation.

With 38.5″ of vertical lift travel and a lift bed height range from 6″ (down) to 44.5″ (up), this system is built to accommodate a wide range of boats with easy shore access. The 114″ inside width and 127″ frame length support larger vessels, and the free-standing frame provides maximum flexibility for shoreline placement.

This lift weighs only 560 lbs and includes four 3′ leveling legs for stability on uneven surfaces. Power options include 12V, 24V, and 220V, with optional upgrades like a pontoon cradle and solar charging package.

Key Features:

Capacity: 5,200 lbs
Lift Travel: 38.5″
Lift Bed Height: 6″ (Down), 44.5″ (Up)
Inside Width: 114″ | Outside Width: 120″
Length: 127″
Unit Weight: 560 lbs
Power Options: 12V, 24V, or 220V
Remote control included
(4) 3′ leveling legs for stability
Optional: Pontoon cradle & solar charging system

A smart upgrade from manual lifts, perfect for boaters who value convenience, power, and durable performance.

We accept

pngimg.com - paypal_PNG7.png__PID:8a7c843a-2227-4649-a602-786624b58d6f

Authorized U.S. Dealer

All Boat Lifts ship directly from certified U.S.-based facilities.

Fast & Free Shipping

Most units are built-to-order and ship quickly with no added delivery fees.

Easy Returns & Exchanges

Eligible systems can be returned within 30 days. We’re here to help if anything’s not right.

Lifetime Support

Call, chat, or email anytime. Our U.S.-based team is ready to assist before and after your purchase.

Cantilever Boat Lift Technical Specifications

Specifications	Details
Lift Capacity	5,200 lbs
Lift Bed Height	44.5″ (Up), 6″ (Down)
Lift Travel	38.5″
Inside Width	114″
Overall Length	127″
Outside Width	120″
Lift Weight	560 lbs
Leveling Legs	(4) 3′ 3″ × 3″ adjustable legs

HydraulicCantilever_cutout.jpg__PID:50244061-863a-4c18-893c-3f959dea9823

CapturePro X200 Technical Specifications

Weather-sealed body

Durable design for shooting in various conditions

Built-in GPS

Automatic photo geotagging for easy organization

Time-lapse feature

Create dynamic time-lapse videos with ease

Cantilever Boat Lift FAQs

Get Answers to Commonly Asked Questions

Does this lift require a permanent dock or piling installation?

No. This is a free-standing lift, which means it does not require piles or permanent dock mounting. It's designed for versatile shoreline placement, making it suitable for seasonal installs or varying water depths.

Is the lift easy to operate for one person?

Absolutely. The included wireless remote control allows you to raise or lower the lift with the push of a button—no manual cranking or physical effort required. It’s engineered for solo operation and maximum ease.

What is included with the lift, and is installation support available?

Each lift includes the full welded aluminum frame, (4) leveling legs, hydraulic power unit, and wireless remote system. While installation is straightforward for most DIY users, we can connect you with support or local installers if needed.

Can this lift be used in deep or fluctuating water levels?

Yes. The adjustable leveling legs and free-standing design make it adaptable to a variety of shoreline conditions, including shallow-to-moderate water depths. For deeper or highly variable water levels, extensions may be available—contact us for guidance.

How does the hydraulic system perform in harsh weather?

The hydraulic system is built for durability with marine-grade components and a sealed pump enclosure. Combined with the all-aluminum frame, the lift is designed to withstand corrosion, UV exposure, and seasonal use in both fresh and saltwater environments.
