HD RAMPS

Semi-Truck Service Ramps

Up to 20,000 lb. per Axle

Request QuoteView Options

HD Ramps Aluminum Semi-Truck Service Ramps

HD Ramps WR-20K: product photograph
HD Ramps WR-20K: detail view 1
HD Ramps WR-20K: detail view 2
Roll over image to zoom in Click on image to zoom
HD Ramps WR-20K: product photographHD Ramps WR-20K: detail view 1HD Ramps WR-20K: detail view 2
Heavy Duty Ramps

HD Ramps Aluminum Semi-Truck Service Ramps

SKU: WR-20K Currently In Stock

$2,656.99 USD

Freight Shipping Available Nationwide

Delivered in 10 to 15 business days

✔ Have Questions? Call a Currenhaus Team Member: (805)-334-5208
✔ Hassle-Free Jobsite Freight Delivery
✔ Authorized U.S. Dealer
✔ Lowest Price Match Guaranteed
Ask a Question or Request a Quote
(805)-334-5208 operations@currenhaus.com

MOST IMPORTANT FEATURES

ALUMINUM CONSTRUCTION

SELECT THE ENGINEERED CONFIGURATION FOR THE WORK AND INSTALLATION.

CONFIGURATION CHOICE

PAIR; 20,000 LB. PER AXLE; STATIONARY SERVICE USE

LOAD LIMITS

UP TO 20,000 LB. PER AXLE. CHECK THE SELECTED SKU’S LIMITS BEFORE USE.

MEASURE BEFORE ORDERING

MEASURE TIRE CONTACT WIDTH AND VERIFY APPROACH AND BUMPER CLEARANCE.

APPLICATION DETAILS

STATIONARY VEHICLE-SERVICE USE; NOT A TRAILER LOADING RAMP.

Description

Key Benefits

Technical Specs

Applications

Semi-Truck Service Ramps

The semi-truck service ramp pair raises a suitable rubber-wheeled commercial vehicle for maintenance and inspection. It is intended for stationary service work rather than loading a vehicle onto a trailer.

The pair is rated for 20,000 lb. per axle and measures 64″ × 16″ per ramp. Aluminum construction keeps each ramp at approximately 48 lb. The 13.25″ overall height includes the ramp structure; it should not be confused with the tire lift height.

Check the heaviest axle, tire width and approach clearance before choosing a service ramp. Position the pair on a firm, level surface, apply the parking brake and chock the wheels that remain on the ground. Follow the manufacturer’s service procedure and use suitable jack stands before working beneath the vehicle. These ramps are not recommended for forklifts, tracked machines, road grinders or rollers.

Semi-Truck Service Ramps

  • The semi-truck service ramp pair raises a suitable rubber-wheeled commercial vehicle for maintenance and inspection. It is intended for stationary service work rather than loading a vehicle onto a trailer.
  • The pair is rated for 20,000 lb. per axle and measures 64″ × 16″ per ramp. Aluminum construction keeps each ramp at approximately 48 lb. The 13.25″ overall height includes the ramp structure; it should not be confused with the tire lift height.
  • Pair; 20,000 lb. per axle; stationary service use.

Semi-Truck Service Ramps

  • WR-20K | Pair | Material: Aluminum; Dimensions (L × W × H): 64″ × 16″ × 13.25″; Rated capacity: 20,000 lb. per axle

Semi-Truck Service Ramps

  • Stationary vehicle-service use; not a trailer loading ramp.
  • Not recommended for forklifts, tracked machines, road grinders or rollers.
  • Overall ramp height and actual tire lift height are separate dimensions.
  • Check the vehicle’s heaviest axle against the pair’s rating.
  • Measure tire contact width and verify approach and bumper clearance.
  • Use on a firm, level surface and inspect both ramps before use.
  • Apply the parking brake and chock the wheels remaining on the ground.
  • Use suitable jack stands before anyone works beneath a vehicle, as directed by the manufacturer.

HD Ramps Product & Manufacturer Videos

Semi-Truck Service Ramps

BUILT FOR THE WORK:

  • Pair; 20,000 lb. per axle; stationary service use.
  • Aluminum construction for the stated application.
  • Up to 20,000 lb. per Axle.
  • Dimensions and connection details vary by SKU.
  • Select the configuration before reviewing the technical specifications.

SET UP FOR YOUR APPLICATION:

  • Check the vehicle’s heaviest axle against the pair’s rating.
  • Measure tire contact width and verify approach and bumper clearance.
  • Use on a firm, level surface and inspect both ramps before use.
  • Apply the parking brake and chock the wheels remaining on the ground.
  • Use suitable jack stands before anyone works beneath a vehicle, as directed by the manufacturer.

READY FOR THE FIELD:

  • Check the vehicle’s heaviest axle against the pair’s rating.
  • Measure tire contact width and verify approach and bumper clearance.
  • Use on a firm, level surface and inspect both ramps before use.
  • Apply the parking brake and chock the wheels remaining on the ground.
  • Use suitable jack stands before anyone works beneath a vehicle, as directed by the manufacturer.
