Indeco

Indeco Mulcher Head

For Heavy Excavators

Indeco

Indeco Mulcher Head – Heavy Excavator IMH Series (IMH-20 & IMH-30)

SKU: IND-IMH20-HX-001 Currently In Stock

Sale price$46,043.00 USD

Most Important Features

EASY MAINTENANCE ACCESS

CENTRALIZED HYDRAULIC PORTS AND GREASING POINTS ENABLE QUICK SERVICE AND MINIMAL DOWNTIME ON THE JOBSITE.

HARDOX® HEAVY-DUTY BUILD

REINFORCED STEEL HOUSING, RUNNERS, AND ROTOR DESIGNED FOR HIGH-IMPACT CLEARING AND LONG-TERM DURABILITY.

WIDE CARRIER COMPATIBILITY

ENGINEERED TO FIT 18-45 TON EXCAVATORS WITH INTERCHANGEABLE MOUNTS AND FLEXIBLE HYDRAULIC FLOW REQUIREMENTS.

HIGH-EFFICIENCY HYDRAULIC FORCE

FIXED-DISPLACEMENT MOTORS DELIVER CONSISTENT TORQUE AND MAXIMUM CUTTING OUTPUT IN DEMANDING FIELD CONDITIONS.

BITE-LIMITER CUTTING POWER

PRECISION-CONTROLLED CUTTING DEPTH FOR FAST, CLEAN MULCHING THROUGH BRUSH, SAPLINGS, AND DENSE VEGETATION.

Description

Key Benefits

Technical Specs

Applications

Indeco Mulcher Head

The Indeco IMH heavy-excavator mulching heads are engineered to convert 18–45 ton carriers into high-output, fully professional forestry and land-clearing machines. Designed for extreme performance, the IMH-20 and IMH-30 combine reinforced HARDOX steel construction, high-capacity hydraulic systems, and large-format cutting rotors to process heavy vegetation, thick brush, and mid-diameter trees with speed, stability, and precision.

These heavy-duty mulchers are built for demanding applications where cutting width, torque, and throughput must remain consistent under challenging material loads. The bite-limiter drum design regulates cutting depth and protects rotor speed, allowing the head to process dense vegetation without stalling or overloading the excavator. Optimized tooth layout and aggressive cutting geometry maximize bite efficiency and ensure clean, controlled mulch output across wide variations in material density.

The IMH-20 and IMH-30 utilize high-displacement, heavy-flow hydraulic motors matched to large excavators running between 45 and 80 GPM. These motors deliver strong, sustained torque and are engineered for continuous-duty performance under high back-pressure. The direct-drive transmission eliminates belt slippage and mechanical loss, providing smooth torque transfer and consistent cutting force across long operational cycles.

Indeco Mulcher Head

  • High-efficiency cutting performance – Bite-limiter drum design maintains optimal cutting depth and rotor speed for consistent mulch quality.
  • Durable HARDOX construction – Heavy-duty body, runners, and components withstand long clearing cycles and abrasive ground conditions.
  • Smooth, controlled operation – Fixed-displacement motors provide stable torque delivery across variable flow ranges.
  • Low vibration cutting – Rotor and tooth layout reduce vibration for more comfortable, precise machine handling.

Indeco Mulcher Head

IMH-20

  • Cutting Width: 42″
  • Hydraulic Flow (GPM): 45–65
  • Number of Teeth: 22
  • Working Weight: 3300 lbs
  • Suitable Carrier: 18–25 ton

IMH-30

  • Cutting Width: 50″
  • Hydraulic Flow (GPM): 55–80
  • Number of Teeth: 22
  • Working Weight: 4250 lbs
  • Suitable Carrier: 30–45 ton

Indeco Mulcher Head

  • Land clearing and heavy vegetation reduction
  • Brush, shrub, and undergrowth removal
  • Forestry management and small-tree processing
  • Roadside, highway, and railway vegetation maintenance
  • Utility line and pipeline corridor clearing
  • Municipal green-space and park maintenance
  • Trail creation, firebreak construction, and habitat restoration
  • Stump, root, and wood-residue reduction during site prep

Indeco Mulcher Head

ENGINEERED FOR POWER:

  • Direct-drive hydraulic system delivers strong, consistent torque
  • Bite-limiter steel profiles maintain optimal cutting depth
  • High-efficiency rotor design processes brush, saplings, and mid-diameter trees
  • Heavy-duty HARDOX housing stands up to continuous forestry work
  • Built for fast vegetation reduction with stable rotor speed under load
  • Durable construction supports long-duty clearing operations

BUILT FOR PRECISION:

  • Fixed-displacement motors optimized for compact excavator flow ranges
  • Smooth cutting action reduces vibration and improves operator control
  • Tooth layout designed for efficient shredding and uniform mulch output
  • Steel runners guide cutting height for accurate, consistent material removal
  • Centralized hydraulic ports and valves ensure stable performance
  • Engineered to minimize stalling and maintain clean cutting lines

READY FOR THE FIELD:

  • Interchangeable mounting points fit a wide range of large carriers
  • Easy-access hydraulic connections and greasing points simplify maintenance
  • Proven reliability in land clearing, utilities, roadside, and forestry environments
  • Supports multiple cutter styles for different terrains (multi-purpose, cobra, carbide)
  • Tough rotor and shaft design built to withstand abrasive and uneven conditions
  • Field-tested durability across brush, roots, stumps, and heavy vegetation
