LOFLIN FABRICATION

60-Inch Open Front Brush Cutter

For Skid Steers & Track Loaders

60" Cutting Width

Request QuoteAdd To Cart

Loflin Fabrication 60-Inch Open Front Brush Cutter For Skid Steers & Track Loaders

Loflin Fabrication 60-Inch Open Front Brush Cutter For Skid Steers & Track Loaders manufacturer family image 1; illustrated configuration may vary
Loflin Fabrication 60-Inch Open Front Brush Cutter For Skid Steers & Track Loaders manufacturer family image 2; illustrated configuration may vary
Loflin Fabrication 60-Inch Open Front Brush Cutter For Skid Steers & Track Loaders manufacturer family image 3; illustrated configuration may vary
Roll over image to zoom in Click on image to zoom
Loflin Fabrication 60-Inch Open Front Brush Cutter For Skid Steers & Track Loaders manufacturer family image 1; illustrated configuration may varyLoflin Fabrication 60-Inch Open Front Brush Cutter For Skid Steers & Track Loaders manufacturer family image 2; illustrated configuration may varyLoflin Fabrication 60-Inch Open Front Brush Cutter For Skid Steers & Track Loaders manufacturer family image 3; illustrated configuration may vary
Loflin Fabrication

Loflin Fabrication 60-Inch Open Front Brush Cutter For Skid Steers & Track Loaders

SKU: 0030101060-80 Currently In Stock

$7,279.99 USD

Freight Shipping Available Nationwide

Delivered in 10 to 15 business days

✔ Have Questions? Call a Currenhaus Team Member: (805)-334-5208
✔ Hassle-Free Jobsite Freight Delivery
✔ Authorized U.S. Dealer
✔ Lowest Price Match Guaranteed

Select Your Machine to Check Compatibility
Ask a Question or Request a Quote
(805)-334-5208 operations@currenhaus.com
Product Catalog Parts & Support

MOST IMPORTANT FEATURES

PROPRIETARY DIRECT DRIVE

A ONE-PIECE HEAT-TREATED FORGED STEEL AXLE TRANSFERS MOTOR POWER THROUGH LOFLIN’S PROPRIETARY DRIVE WITHOUT A GEARBOX.

BI-DIRECTIONAL CUTTING

FULLY HEAT-TREATED FORGED BLADES ARE DESIGNED FOR OPERATION IN BOTH DIRECTIONS OF ROTATION.

1/4-INCH REINFORCED DECK

A REINFORCED 1/4-INCH STEEL DECK FORMS THE CUTTER HOUSING.

ENCLOSED MOTOR AND DRIVE

THE MOTOR AND DRIVE ASSEMBLY ARE ENCLOSED TO REDUCE EXPOSURE OF THE WORKING COMPONENTS DURING BRUSH CUTTING.

MATCHED MOTOR SELECTION

SELECT THE MOTOR DISPLACEMENT FOR THE CHOSEN CUTTER WIDTH AND THE CARRIER’S AUXILIARY FLOW. A MOTOR CODE ALONE DOES NOT ESTABLISH A PRESSURE MATCH.

Description

Key Benefits

Technical Specs

Applications

Loflin 60-Inch Open Front Brush Cutter

The Loflin Fabrication 60-Inch Open Front Brush Cutter is an open-front rotary cutter for vegetation maintenance, overgrown areas, and access-route clearing. Its 60-inch working width is offered with the motor options in the selector.

Loflin’s proprietary direct drive combines a one-piece heat-treated forged steel axle, an iron housing, and oversized tapered roller bearings. A reinforced 1/4-inch deck surrounds an enclosed motor and drive assembly.

Bi-directional forged blades cut in either direction, with pressure relief in both directions of rotation. Select the two- or three-blade configuration for this 60-inch cutter.

Match the selected motor’s flow range to your machine’s auxiliary circuit and confirm the operating pressure before ordering. Confirm exact skid-steer quick-attach interface. Carrier lift capacity and attachment weight must also be checked separately.

Loflin 60-Inch Open Front Brush Cutter

  • A one-piece heat-treated forged steel axle transfers motor power through Loflin’s proprietary drive without a gearbox.
  • Fully heat-treated forged blades are designed for operation in both directions of rotation.
  • A reinforced 1/4-inch steel deck forms the cutter housing.
  • The motor and drive assembly are enclosed to reduce exposure of the working components during brush cutting.
  • Select the motor displacement for the chosen cutter width and the carrier’s auxiliary flow. A motor code alone does not establish a pressure match.

Loflin 60-Inch Open Front Brush Cutter

  • Manufacturer: Loflin Fabrication
  • Family: 60-Inch Open Front Brush Cutter
  • Carrier group: Skid Steers & Track Loaders
  • Mount: Confirm exact skid-steer quick-attach interface.
  • Hydraulic pressure: applicable operating limits require manufacturer verification.
  • 0030101060-80: 60" EXPOSED BLADE BRUSH CUTTER W/80CC MOTOR 2 BLADE (12-17GPM); 1142 lb weight; 12–17 GPM
  • 0030101060-100: 60" EXPOSED BLADE BRUSH CUTTER W/100CC MOTOR 2 BLADE (15-22GPM); 1142 lb weight; 15–22 GPM
  • 0030101060-120: 60" EXPOSED BLADE BRUSH CUTTER W/125CC MOTOR 2 BLADE (21-28GPM); 1142 lb weight; 21–28 GPM
  • 0030101060-160: 60" EXPOSED BLADE BRUSH CUTTER W/160CC MOTOR 2 BLADE (28-34GPM); 1142 lb weight; 28–34 GPM
  • 0030101060-200: 60" EXPOSED BLADE BRUSH CUTTER W/200CC MOTOR 2 BLADE (35-43GPM); 1172 lb weight; 35–43 GPM
  • 0032101060-80: 60" EXPOSED BLADE BRUSH CUTTER W/80CC MOTOR 3 BLADE (12-17GPM); 1182 lb weight; 12–17 GPM
  • 0032101060-100: 60" EXPOSED BLADE BRUSH CUTTER W/100CC MOTOR 3 BLADE (15-22GPM); 1182 lb weight; 15–22 GPM
  • 0032101060-125: 60" EXPOSED BLADE BRUSH CUTTER W/125CC MOTOR 3 BLADE (21-28GPM); 1182 lb weight; 21–28 GPM
  • 0032101060-160: 60" EXPOSED BLADE BRUSH CUTTER W/160CC MOTOR 3 BLADE (28-34GPM); 1182 lb weight; 28–34 GPM
  • 0032101060-200: 60" EXPOSED BLADE BRUSH CUTTER W/200CC MOTOR 3 BLADE (35-43GPM); 1202 lb weight; 35–43 GPM

Loflin 60-Inch Open Front Brush Cutter

  • Vegetation and brush maintenance with a properly matched hydraulic carrier.
  • Maintaining access routes, trails, field edges, and overgrown areas.
  • Match the cutter configuration to vegetation, terrain, and the carrier’s hydraulic output.
  • Use the manufacturer’s guarding, operating procedure, and required exclusion area.

Loflin Fabrication: Brush Cutter Demonstrations & Brand Videos

Loflin 60-Inch Open Front Brush Cutter

PURPOSE-BUILT CUTTING SYSTEM:

  • A one-piece heat-treated forged steel axle transfers motor power through Loflin’s proprietary drive without a gearbox.
  • Fully heat-treated forged blades are designed for operation in both directions of rotation.
  • A reinforced 1/4-inch steel deck forms the cutter housing.
  • The motor and drive assembly are enclosed to reduce exposure of the working components during brush cutting.
  • Select the motor displacement for the chosen cutter width and the carrier’s auxiliary flow. A motor code alone does not establish a pressure match.

MATCH THE CUTTER TO THE MACHINE:

  • 60-inch cutting width.
  • Choose the exact motor configuration offered for this product family.
  • Confirm exact skid-steer quick-attach interface.
  • Confirm auxiliary pressure and any case-drain requirement.
  • Account for cutter weight and the carrier’s permitted load position.

READY FOR THE FIELD:

  • Choose the 60-inch open front brush cutter configuration.
  • Confirm the machine’s auxiliary circuit against the selected motor.
  • Inspect the blades, mounting engagement, hoses, and guards.
  • Follow manufacturer requirements for operator protection and bystander separation.
  • Verify attachment weight, hydraulic settings, and required mounting hardware before operation.
