Millcreek

Arena Rake

For Arenas & Infields

Up to 7 ft Grooming Width

Request QuoteAdd To Cart

Millcreek Spin Groomer Arena Rake

Millcreek spin groomer arena rake
Millcreek spin groomer arena rake
Millcreek spin groomer arena rake
Millcreek spin groomer arena rake
Roll over image to zoom in Click on image to zoom
Millcreek spin groomer arena rakeMillcreek spin groomer arena rakeMillcreek spin groomer arena rakeMillcreek spin groomer arena rake
Millcreek

Millcreek Spin Groomer Arena Rake

SKU: 94815 Currently In Stock

$7,499.99 USD

Freight Shipping Available Nationwide

Delivered in 10 to 15 business days

✔ Have Questions? Call a Currenhaus Team Member: (805)-334-5208
✔ Hassle-Free Jobsite Freight Delivery
✔ Authorized U.S. Dealer
✔ Lowest Price Match Guaranteed
Ask a Question or Request a Quote
(805)-334-5208 operations@currenhaus.com
Product Manual Find Parts

MOST IMPORTANT FEATURES

THREE GROOMING WIDTHS

CHOOSE A 5-, 6-, OR 7-FOOT ROTARY ARENA RAKE TO MATCH THE TRACTOR AND WORKING AREA.

GROUND-DRIVEN ROTATION

THE RAKE SPINS AS IT IS PULLED, MOVING MATERIAL SIDEWAYS WITHOUT A PTO CONNECTION.

ADJUSTABLE GROOMING DEPTH

THREE-POINT HITCH TILT SUPPORTS MILD OR AGGRESSIVE GROOMING, WITH UP TO 5 INCHES OF TINE PENETRATION.

RAKE ATTACHMENT INCLUDED

THE INCLUDED RAKE SMOOTHS THE SURFACE AFTER THE ROTARY GROOMING ACTION FOR A MORE UNIFORM FINISH.

STEEL TINES AND BEARINGS

FLAME-HARDENED STEEL TINES AND TAPERED WHEEL BEARINGS SUPPORT REPEATED ARENA AND INFIELD MAINTENANCE.

Description

Key Benefits

Technical Specs

Applications

Millcreek 5, 6 & 7 Foot Spin Groomer Arena Rake

The Millcreek Spin Groomer Arena Rake loosens and levels compacted equestrian footing, baseball infields, and softball fields. Available in 5-, 6-, and 7-foot sizes, the rotary rake spins as the tractor pulls it across the surface. Its rotating action moves material sideways to help fill rutted paths and low areas, while the included rake attachment smooths the surface behind the grooming action.

The three-point tractor hitch controls rake tilt, allowing mild surface grooming or a more aggressive pass. At maximum tilt, the tines can work up to 5 inches deep. All-steel construction, tapered wheel bearings, and flame-hardened steel tines support repeated arena and infield maintenance. Ground contact drives the rotation, so the implement works without a PTO connection.

Match the grooming width to tractor power and the outside-to-outside tire span. The 5-foot model requires 22 HP and a 48-inch tire span; the 6-foot model requires 25 HP and a 60-inch tire span; the 7-foot model requires 30 HP and a 72-inch tire span. Each configuration includes the rake attachment. Adjust hitch tilt to the footing condition and the desired finish before making each grooming pass.

Millcreek 5, 6 & 7 Foot Spin Groomer Arena Rake

  • Three grooming widths: Choose a 5-, 6-, or 7-foot rotary arena rake to match the tractor and working area.
  • Ground-driven rotation: The rake spins as it is pulled, moving material sideways without a pto connection.
  • Adjustable grooming depth: Three-point hitch tilt supports mild or aggressive grooming, with up to 5 inches of tine penetration.
  • Rake attachment included: The included rake smooths the surface after the rotary grooming action for a more uniform finish.
  • Steel tines and bearings: Flame-hardened steel tines and tapered wheel bearings support repeated arena and infield maintenance.

Millcreek 5, 6 & 7 Foot Spin Groomer Arena Rake

Widths: 5 / 6 / 7 ft

Connection: Three-point tractor hitch

Drive: Ground-contact rotation

PTO connection: Not required

Maximum tine depth: 5 in. at maximum tilt

5 ft minimum power: 22 HP

6 ft minimum power: 25 HP

7 ft minimum power: 30 HP

5 ft tractor tire span: 48 in.

6 ft tractor tire span: 60 in.

7 ft tractor tire span: 72 in.

Tire span measurement: Outside to outside

Frame: All steel

Tines: Flame-hardened steel

Bearings: Tapered wheel bearings

Included attachment: Rake attachment

Millcreek 5, 6 & 7 Foot Spin Groomer Arena Rake

  • Equestrian arena footing maintenance.
  • Baseball infield grooming.
  • Softball infield surface conditioning.
  • Loosening compacted footing and rutted paths.
  • Smoothing low spots and maintaining a uniform working surface.

SEE MILLCREEK EQUIPMENT AT WORK

Millcreek 5, 6 & 7 Foot Spin Groomer Arena Rake

ENGINEERED FOR POWER:

  • 5-, 6-, and 7-foot size choices.
  • Ground-contact rotary grooming action.
  • Three-point tractor hitch connection.
  • Works without a PTO connection.
  • Rake attachment included with each size.

BUILT FOR PRECISION:

  • Hitch tilt controls grooming intensity.
  • Tines work up to 5 inches deep at maximum tilt.
  • Sideways material movement fills low areas.
  • Flame-hardened steel tines.
  • Rear rake smooths the groomed surface.

READY FOR THE FIELD:

  • All-steel construction.
  • Tapered wheel bearings support repeated use.
  • 5 ft: 22 HP and 48-inch tractor tire span.
  • 6 ft: 25 HP and 60-inch tractor tire span.
  • 7 ft: 30 HP and 72-inch tractor tire span.
