- Capacity (Struck): 5.8 cu yd – 588 | 10.2 cu yd – 1028
- Capacity (Heaped): 7.8 cu yd – 588 | 13.5 cu yd – 1028
- Maximum Payload: 6,000 lbs – 588 | 10,500 lbs – 1028
- Overall Dimensions (W × L × H): 85” × 17’ 0” × 6’ 6” – 588 | 85” × 23’ 0” × 6’ 10” – 1028
- Body Width: 54”
- Empty Weight: 3,200 lbs – 588 | 4,200 lbs – 1028
- Apron Chain Type: #667 Pintle
- Minimum Hydraulic Flow: 14 GPM (Hydraulic) | Not required (PTO)
- Required Horsepower: 40 hp – 588 | 80 hp – 1028
- Drive Options: Tractor Hydraulic or PTO Hydraulic Drive
- Heavy-duty construction built for high-capacity loads
- Precision discharge system for uniform mulch application
- Handles materials from fine sawdust to coarse bark
- Electric hydraulic controls available for in-cab adjustments
- Designed for orchards, vineyards, berry farms, and commercial landscaping
Features
Specifications
Description
Shipping
Warranty
Specifications
Capacity (Struck)
Capacity (Heaped)
Maximum Payload
Overall Dimensions (W × L × H)
Body Width
Weight (Empty)
Apron Chain Type
Minimum Hydraulic Flow (GPM)
Required Horsepower
588
5.8 cubic yards
7.8 cubic yards
6,000 lbs of material
85" W × 17' 0" L × 6' 6" H
54"
3,200 lbs
#667 Pintle
14 GPM (Hydraulic Drive Models)
40 hp
1028
10.2 cubic yards
13.5 cubic yards
10,500 lbs of material
85" W × 23' 0" L × 6' 10" H
54"
4,200 lbs
#667 Pintle
PTO drive only – no hydraulic flow required
80 hp
