John Deere G Series Windshield

Replacement Cab Panel

1/4-1/2 Inch Panel Options

Request QuoteAdd To Cart

SHIELDS John Deere G Series Polycarbonate Windshield

SHIELDS John Deere G Series Polycarbonate Windshield - product view
SHIELDS John Deere G Series Polycarbonate Windshield - manufacturer view 2
SHIELDS John Deere G Series Polycarbonate Windshield - manufacturer view 3
Roll over image to zoom in Click on image to zoom
SHIELDS John Deere G Series Polycarbonate Windshield - product viewSHIELDS John Deere G Series Polycarbonate Windshield - manufacturer view 2SHIELDS John Deere G Series Polycarbonate Windshield - manufacturer view 3
SHIELDS

SHIELDS John Deere G Series Polycarbonate Windshield

SKU: Availability confirmed before order

$2,039.99 USD

Freight $100 flat freight to the contiguous U.S.

Contact us for current availability and delivery timing.

✔ Have Questions? Call a Currenhaus Team Member: (805)-334-5208
✔ Hassle-Free Jobsite Freight Delivery
✔ Authorized U.S. Dealer
✔ Lowest Price Match Guaranteed
Ask a Question or Request a Quote
(805)-334-5208 operations@currenhaus.com
Product Information Parts & Support

MOST IMPORTANT FEATURES

FORMED POLYCARBONATE

THE FORMED POLYCARBONATE PANEL REPLACES A MATCHING ORIGINAL CAB WINDOW CONFIGURATION.

TWO-SIDED ABRASION COATING

ABRASION-RESISTANT COATING IS APPLIED TO BOTH PANEL SURFACES TO SUPPORT SURFACE DURABILITY.

PANEL THICKNESS CHOICES

CHOOSE A 1/4-INCH OR 1/2-INCH PANEL FROM THE AVAILABLE THICKNESS AND FINISH OPTIONS.

MACHINE-SPECIFIC PROFILE

THE PANEL PROFILE IS INTENDED FOR THE JOHN DEERE G SERIES DOOR CONFIGURATION; COMPARE THE EXACT DOOR AND WIPER LAYOUT.

REPLACEMENT PANEL ONLY

THE INDIVIDUALLY BOXED PANEL IS SUPPLIED WITHOUT THE CAB FRAME, SEALS OR MOUNTING HARDWARE.

Description

Key Benefits

Technical Specs

Applications

SHIELDS John Deere G Series Polycarbonate Windshield

SHIELDS John Deere G Series Polycarbonate Windshield replaces a matching cab window panel with formed polycarbonate. The panel is manufactured by SHIELDS and supplied through Express Steel for the specified machine and door configuration.

Abrasion-resistant coating on both sides helps maintain the panel surface during regular use and cleaning. Choose the required thickness and clear or tinted finish from the available panel options. The panel is individually boxed for transport.

Machine applications: 320G, 324G, 325G, 330G, 331G, 332G and 333G with factory glass. For machines originally fitted with glass, not polycarbonate. Does not fit 312GR, 314G, 316GR, 317G or 318G, and is not an E Series door. The G door uses two hinge holes; the D door has four. Older G models may have the milled wiper reinforcement for 2020+ machines.

The replacement panel must match the original door profile, mounting holes and wiper arrangement. This listing includes the panel only; the frame, seals and mounting hardware are not included. Confirm the exact replacement configuration before ordering.

SHIELDS John Deere G Series Polycarbonate Windshield

  • The formed polycarbonate panel replaces a matching original cab window configuration.
  • Abrasion-resistant coating is applied to both panel surfaces to support surface durability.
  • Choose a 1/4-inch or 1/2-inch panel from the available thickness and finish options.
  • The panel profile is intended for the John Deere G Series door configuration; compare the exact door and wiper layout.
  • The individually boxed panel is supplied without the cab frame, seals or mounting hardware.

SHIELDS John Deere G Series Polycarbonate Windshield

  • Manufacturer: SHIELDS
  • Supplied through: Express Steel
  • Machine applications: 320G, 324G, 325G, 330G, 331G, 332G and 333G with factory glass
  • Fit requirements: For machines originally fitted with glass, not polycarbonate. Does not fit 312GR, 314G, 316GR, 317G or 318G, and is not an E Series door. The G door uses two hinge holes; the D door has four. Older G models may have the milled wiper reinforcement for 2020+ machines.
  • 1/4-Inch Clear: 30 lb
  • 1/2-Inch Clear: 35 lb
  • 1/2-Inch Tinted: 35 lb
  • Material: Formed polycarbonate
  • Coating: Abrasion-resistant on both sides
  • Installation: Match existing door profile, mounting holes and hardware
  • Included: One replacement panel in the selected configuration
  • Excluded: Frame, seals and mounting hardware

SHIELDS John Deere G Series Polycarbonate Windshield

  • Replacing a matching machine cab window panel.
  • Applications within the John Deere G Series door family.
  • Choose the thickness and finish required for the existing panel setup.
  • Confirm the hole pattern, hinge arrangement and wiper configuration.
  • No hydraulic PowerFit test applies; exact physical panel fit must be confirmed.

Express Steel: Supplier Brand & Attachment Videos

SHIELDS John Deere G Series Polycarbonate Windshield

BUILT FOR YOUR WORK:

  • The formed polycarbonate panel replaces a matching original cab window configuration.
  • Abrasion-resistant coating is applied to both panel surfaces to support surface durability.
  • Choose a 1/4-inch or 1/2-inch panel from the available thickness and finish options.
  • The panel profile is intended for the John Deere G Series door configuration; compare the exact door and wiper layout.
  • The individually boxed panel is supplied without the cab frame, seals or mounting hardware.

MATCH YOUR WORKING SETUP:

  • Replacing a matching machine cab window panel.
  • Applications within the John Deere G Series door family.
  • Choose the thickness and finish required for the existing panel setup.
  • Confirm the hole pattern, hinge arrangement and wiper configuration.
  • No hydraulic PowerFit test applies; exact physical panel fit must be confirmed.

READY FOR THE FIELD:

  • Confirm the exact machine model and door series.
  • Identify whether the existing panel is glass or polycarbonate.
  • Compare hinge holes, lower holes and wiper-arm configuration.
  • Choose the correct thickness and finish.
  • Confirm seals, hardware and installation materials before ordering.
